WAVECOR ALUMINIUM CONE FULLRANGE FR070WA02
Puissance 10 Watts
| Nominal size | 2 3/4 | inch |
| Nominal impedance | 8 | ohm |
| Recommended frequency range | 80-28K | Hz |
| Sensitivity, 2.83V/1m (average SPL in range 2 - 20 kHz) | 83.5 | dB |
| Effective radiating area, Sd | 21 | sq.cm |
| Resonance frequency (free air, no baffle), Fs | 117 | Hz |
| Moving mass, incl. air (free air, no baffle), Mms | 1.9 | g |
| Force factor, Bxl | 3.6 | |
| Suspension compliance, Cms | 0.97 | mm/N |
| Equivalent air volume, Vas | 0.61 | l |
| Mechanical resistance, Rms | 0.12 | Ns/m |
| Mechanical Q, Qms | 11.7 | |
| Electrical Q, Qes | 0.69 | |
| Total Q, Qts | 0.65 | |
| Voice coil resistance, RDC | 6.4 | ohm |
| Voice coil inductance, Le (measured at 10 kHz) | 110 | µH |
| Voice coil inside diameter | 22 | mm |
| Voice coil winding height | 7 | mm |
| Air gap height | 3 | mm |
- MARQUE WAVECOR
- MEMBRANE ALUMINIUM
- TAILLE 5.0-7.0 cm
- TYPE LARGE BANDE
- FR070WA01_02_specifications
FR070WA01_02_specifications_fr
