WAVECOR TEXTILE DOME TWEETER TW030WA10
| Nominal size | 30 | mm |
| Nominal impedance | 8 | ohm |
| Recommended frequency range | 2.-27 | kHz |
| Sensitivity, 2.83V/1m (average SPL in range 2 - 20 kHz) | 90 | dB |
| Effective radiating area, Sd | 11.5 | sq.cm |
| Resonance frequency (free air, no baffle), Fs | 750 | Hz |
| Moving mass, incl. air (free air, no baffle), Mms | 0.42 | g |
| Force factor, Bxl | 2.4 | |
| Suspension compliance, Cms | 0.11 | µm/N |
| Equivalent air volume, Vas | 0.02 | litres |
| Mechanical resistance, Rms | 0.25 | Ns/m |
| Mechanical Q, Qms | 7.8 | |
| Electrical Q, Qes | 2.17 | |
| Total Q, Qts | 1.7 | |
| Voice coil resistance, RDC | 6.3 | ohm |
| Voice coil inductance, Le (measured at 10 kHz) | µH | |
| Voice coil inside diameter | 30.4 | mm |
| Voice coil winding height | 1.7 | mm |
| Air gap height | 2.5 | mm |
| Theoretical linear motor stroke, Xmax | 0.4 | mm |
| Magnet weight | g | |
| Total unit net weight excl. packaging | kg |
- MARQUE WAVECOR
- MEMBRANE TISSU
- TAILLE 10-11 cm
- TYPE AIGU
