WAVECOR TEXTILE DOME TWEETER TW030WA09
| Nominal size | 30 | mm |
| Nominal impedance | 4 | ohm |
| Recommended frequency range | 700-30K | Hz |
| Sensitivity, 2.83V/1m (average SPL in range 2 - 20 kHz) | 93 | dB |
| Effective radiating area, Sd | 10.3 | sq.cm |
| Resonance frequency (free air, no baffle), Fs | 470 | Hz |
| Mechanical Q, Qms | 3.2 | |
| Electrical Q, Qes | 0.89 | |
| Total Q, Qts | 0.7 |
- MARQUE WAVECOR
- MEMBRANE TISSU
- TAILLE 10-11 cm
- TYPE AIGU
