WAVECOR TEXTILE DOME TWEETER TW022WA06
| Nominal size | 22 | mm |
| Nominal impedance | 4 | ohm |
| Recommended frequency range | 2-25 | kHz |
| Sensitivity, 2.83V/1m (average SPL in range 2 - 20 kHz) | 90.5 | dB |
| Effective radiating area, Sd | 6.1 | sq.cm |
| Resonance frequency (free air, no baffle), Fs | 750 | Hz |
| Moving mass, incl. air (free air, no baffle), Mms | 0.3 | g |
| Force factor, Bxl | 1.9 | |
| Suspension compliance, Cms | 0.15 | µm/N |
| Equivalent air volume, Vas | 7.9 | ml |
| Mechanical resistance, Rms | 0.57 | Ns/m |
| Mechanical Q, Qms | 2.5 | |
| Electrical Q, Qes | 1.45 | |
| Total Q, Qts | 0.92 | |
| Voice coil resistance, RDC | 3.7 | ohm |
| Voice coil inductance, Le (measured at 10 kHz) | 36 | µH |
| Voice coil inside diameter | 22 | mm |
| Voice coil winding height | 1.8 | mm |
| Air gap height | 2.5 | mm |
| Theoretical linear motor stroke, Xmax | 0.35 | mm |
| Magnet weight | 140 | g |
| Total unit net weight excl. packaging | 0.35 | kg |
| Krm | 0.0083 | mohm |
| Erm | 1.03 | |
| Kxm | 1.04 | mH |
| Exm | 0.67 |
- MARQUE WAVECOR
- MEMBRANE TISSU
- TAILLE 10-11 cm
- TYPE AIGU
- TW022WA06_specifications
TW022WA06_specifications_fr
